DZK series vacuum hot pressing furnace
DZK series vacuum hot pressing furnace is mainly used for sintering at high temperature and pressure of high temperature ceramic materials (BN, Al2O3 with high purity), high temperature photovoltaic materials (ZrO2, LaB6) and other materials. It can also be used for pressure, diffusion and welding of precious metals and precious materials.
Device structure – front door, horizontal and single-chamber, furnace is composed of furnace body, hydraulic pressure system, flame tube, vacuum system, rapid gas filling system, air cooling system, electric control system, water cooling system, truck outside the furnace.
General technical indicators and size of common types of furnaces (about other special indicators, please call us)
Ultimate vacuum: 6.7×10-3Pa
The pressure of cooling gas: ＜1bar
Temperature uniformity in the furnace: ±5℃ or ±3℃
Type
|
Size of heating zone (mm)
| Mass of Load (kg)
| Maximum temperature (℃)
|
Heating power (kW) |
Physical pressure (t)
|
DZK-150 | 400×400×400 | 150 | 1400 | 150 | 50 |
DZK-200 | 600×600×600 | 300 | 1400 | 200 | 80 |
DZK-360 | 900×900×900 | 500 | 1400 | 360 | 100 |
DZK-600 | 1200×1200×1200 | 2000 | 1400 | 600 | 200 |
